| Dial Size (mm) | 100 |
| Mounting | Bottom / Lower Back with Panel / Bottom with Surface |
| Case | Alluminum Die Cast / AISI 304 SS |
| Range | -1.0 to 0 & 0 to 150 Kg/cm² |
| Accuracy | ±1.6% of F.S |
| Bourdon Tube | Inconel |
| Sensing Element | Diaphragm |
| Capillary | AISI 304 SS |
| Connection Size | 3/8”, 1/2", Flange |
| Connection Type | NPT, G, R |
| Option | "0" Adjustable Pointer |
