DIAPHRAGM SEAL FLUSH DIAPHRAGM, SANITARY TYPE - MODEL CSE

CSE (Flush Diaphragm, Sanitary Type)
Range -1 to 40 kg/cm²
Instrument Connection 1/2" BSP(F)
Process Connection As per DIN, SMS, RJT
Diaphragm AISI 316L SS, Monel, Hastelloy C
Body AISI 316 SS
Filling Fluid Glycerin
Compatible Models PM, PB, PS, PJ
Options With Capillary

Download Send Enquiry

Applications

  • Diaphragm seals are provided in the instruments like pressure gauges, switches, transmitters in order to isolate the sensing element from the main service due to its corrosive, viscous and sedimented nature and to avoid clogging and solidification.
  • These seals are specially designed for applications where high purity in the process is essential.- typically in food, beverages, dairy and pharmaceutical industries.
