POLYPROPYLENE CASE PRESSURE GAUGE BOURDON TUBE TYPE - MODEL PP

PP (High Safety - Polypropylene Case)
Reference Standard ANSI B 40.1
Nominal Dial Size (mm) 125 (4½")
Range -1 to 0, 0 to 0.6, 0 to 1600 kg/cm²
Accuracy ±0.5% of F.S / ±1.0% of F.S
Mounting Type Click Here
Connection Size 1/4” , 3/8”, 1/2", M20
Socket AISI 316L SS / Monel
Sensing Element AISI 316L SS / Monel (Bourdon)
Case & Bezel Polypropylene
Pointer Aluminium, Zero Adjustable
Movement AISI 304 SS / AISI 316 SS
Window (Glass) Shatterproof / Plexy / Toughened
Enclosure Protection IP 65 / IP 66 / IP 67
Options Dampening Liquid Glycerine Filled
Conformity as per NACE Standard
Ammonia Range (Temperature scale)
Oxygen Service (For Dry Version)

Download Send Enquiry

Applications

  • Suitable for High Pressure Gas
