STAINLESS STEEL CASE TEST GAUGE (ACC. ±0.25%)BOURDON TUBE TYPE - MODEL PR

PR (Test Gauge)
Reference Standard EN 837-1 / IS 3624
Nominal Dial Size (mm) 150, 250
Range 0 to 0.6, 0 to 600 kg/cm²
Accuracy ±0.25% of F.S.
Mounting Type Click Here
Connection Size 1/4” , 3/8”, 1/2", M20
Connection Type NPT, BSP, G, R, Metric etc
Socket AISI 316L SS
Bourden Type Beryllium Copper
Case & Bezel Bayonet AISI 304 SS / AISI 316 SS
Pointer Aluminium, Knife Edge Micrometer Adjustable
Movement High Precision Jewel Bearing Type
Window (Glass) Shatterproof
Enclosure Protection IP 65
Carrying Case Wooden Carrying Case
Calibration Certificate Traceable to National / International Standard

Download Send Enquiry

Applications

  • Calibration/Testing in laboratory
  • Fits for various process Industries and all gaseous/ Liquid media that will not obstruct the pressure system.
