THERMOWELLS PARTIAL OVERLYING (BAR STOCK & PIPE - FLANGED) - MODEL TW8

TW8
Construction Partial Overlying Type
Flange Facing Type Flange
Form of Shank Straight
Material of Construction AISI 304 SS / AISI 304L SS / AISI 316 SS / AISI 316L SS
Process Connection Flange 1" to 5" as per ANSI/JIS/DIN/BS
Instrument Connection 1/2" to 1" NPT, BSP, G, R
Bore Diameter/Pipe Size 6.5, 6.6, 7.0, 8.0, 8.5, 9.0, 10.0, 10.5, 11.0, 13.0, 13.50
Type Of Head Round
Ext / Lagging Length 50mm
Insertion Length Upto 1000 mm
Options Plug & Chain in AISI 304 SS
Conformity as per NACE Standard

Download Send Enquiry

Applications

  • Chemical & Petrochemical Plants
  • On Shore & Off Shore
  • Engineering
  • Other similar process Industries
