| Construction | Sanitary Design - Drilled Type |
| Connection Type | Triclover |
| Form of Shank | Straight / Straight Reduce Tip / Partial Taper / Full Taper |
| Material of Construction | AISI 304 SS / AISI 304L SS / AISI 316 SS / AISI 316L SS |
| Process Connection | 1½", 2", 2½" Sanitary Seal |
| Instrument Connection | 3/8" to 3/4" NPT, BSP, G, R |
| Bore Diameter/Pipe Size | 6.5, 6.6, 7.0, 8.0, 8.5, 9.0, 10.0, 10.5, 11.0, 13.0, 13.50 |
| Type Of Head | Round with Spanner Slot |
| Ext / Lagging Length | 50mm |
| Insertion Length | 1000 mm (Max) |
| Options | Tri Clamp with Gasket Electo Polishing Conformity as per NACE Standard |
