NEEDLE VALVES & MANIFOLDS - NEEDLE VALVE - MODEL VC6

VC6
Mounting Type Pipe to Pipe (Direct)
Special Features 1 Inlet & 1 Outlet
M.O.C. of Body AISI 316 SS
Stem Packing PTFE, Graphoil
Pressure Rating 6000 PSI
Temperature Rating 240°C
Process Connection 6mm………12mm, 1/4" to 1"
Thread Type NPT, BSP, G, R, Metric etc
Connection (Inst. x Proc.) Tube x Tube, Tube x Male, Tube x Female
Options Conformity as per NACE Standard
Oxygen Service, Other MOC available on request
