THERMOCOUPLE NIPPLE EXTENSION - MODEL TC01

TC01 (Nipple Extension / Nipple Union Extension)
Sensor Type K (NiCr-Ni)
No. Of Element Simplex/Duplex
Connection Type Nipple Extension / Nipple Union Extension
Hot End Termination Ungrounded Junction
Accuracy Class “2” Tolerance as per IEC - 584.2
Sheath Diameter 6mm, 6.35mm, 3mm, 8mm
Sheath Material AISI 316 SS
Enclosure Protection IP 65/Flame Proof/Explosion proof
Enclosure Material Die-cast Aluminum/ AISI 304 SS
Process Connection Size 1/2”, 3/4”, 3/8”, M20
Process Connection Type NPT, BSP, G, R, Metric etc
Options ATEX, CSA & FM (Enclosure)
With Thermowell
With Cable Gland

Download Send Enquiry

Applications

  • Oil & Gas Industries
  • Chemical & Petrochemical Industries
  • Water & Waste-water Treatment
  • Power & Utilities
