DIFFERENTIAL PRESSURE GAUGE CAPSULE TYPE - MODEL PCD

PCD (Capsule Operated)
Standard Follows EN 837-3
Nominal Dial Size (mm) 100, 150
Range 0 to 400 mbar
Accuracy ±1.6% of F.S
Mounting Type Bottom / Back / with Bracket
Connection Size 2 x 1/2" NPT(F) or BSP(F)
Wetted Part AISI 316L SS
Case & Bezel Bayonet AISI 304 SS
Pointer Aluminium, Black
Movement Brass Nickel Plated
Window (Glass) Macrolon 8mm
Static Pressure Max. 1.5 kg/cm²
Options With Manifold, Other connection available
With Swivel Adaptors

Download Send Enquiry

Applications

  • Flow measurement
  • Heating and ventilation
  • Filter applications
  • General industry
  • Oil and gas industry
