RESISTANCE TEMPERATURE DETECTOR PLUG & JACKS CONNECTOR - MODEL RTD04

RTD04 (Plug & Jack connector)
Sensor Pt-100
No. Of Element Simplex/Duplex
Head Extension type Plug & Jack connector
Wire Configuration 3 Wires
Range -200°C up to 400°C
Accuracy Class “B” As per IEC - 751 / DIN - 43760
Sheath Diameter 6 mm, 6.35mm, 3mm, 8mm
Sheath Material AISI 316 SS
Element Length 300mm
Process Connection Size 1/2”, 3/4”, 3/8”, M20
Process Connection Type NPT, BSP, G, R, Metric etc

Download Send Enquiry

Applications

  • Power & Utilities
  • Auto-clave Applications
  • Pharmaceutical
