RESISTANCE TEMPERATURE DETECTOR THREADED / FLANGED - MODEL RTD05

RTD05 (Flanged)
Sensor Pt-100
No. Of Element Simplex/Duplex
Head Extension type Flanged
Wire Configuration 3 Wires
Range -200°C up to 400°C
Accuracy Class “B” As per IEC - 751 / DIN - 43760
Sheath Diameter 6mm, 6.35mm, 3mm, 8mm
Sheath Material AISI 316 SS
Enclosure Protection IP 65/Flame Proof/Explosion proof
Enclosure Material Die-cast Aluminum/ AISI 304 SS
Process Connection Flange as per ANSI/JIS/DIN/BS
Immersion Length 300mm
Extension Length 100mm
Options ATEX, CSA & FM (Enclosure)

Download Send Enquiry

Applications

  • Oil & Gas Industries
  • Chemical & Petrochemical Industries
  • Water & Waste-water Treatment
  • Power & Utilities
  • Air & Flue gas Service
  • Furnaces, Kilns & Ovens
