STAINLESS STEEL INDUSTRIAL THERMOMETER BIMETAL TYPE - MODEL TG1

TG1 (All Stainless Steel : Bi-Metal Type)
Standard Follows EN 13190
Nominal Dial Size (mm) 63, 100, 125, 150
Range -50°C to 500°C
Accuracy Class 1 as per EN 13190
Sensing Element Bi-Metal Strip Coiled
Connection Size 1/2"
Connection Type NPT, BSP, G, R
Stem & Connection AISI 316 SS
Stem Diameter 6, 6.35, 8, 10, 12
Case, Bezel & Clamp AISI 304 SS
Pointer Aluminium, Black
Mounting Type Direct Bottom, Direct Back, Every Angle Back
Options Available with Thermowell
Dampening Liquid Glycerin Filled
Dampening Liquid Silicon Filled

Download Send Enquiry

Applications

  • Chemical, Refinery
  • Food & Beverage
  • Pharmaceutical
  • Breweries
  • Conventional
  • Nuclear power plant
  • Clean Air & Gaseous
