EXPLOSION PROOF TYPE

EXPLOSION PROOF TYPE
Mounting Bottom / Back / Top with Panel
Dial Size 75mm, 100mm
Explosion d2G4 / Exd IIB + H2T4
Case Alluminum Die Cast
Case Colour Black
Range -200 to 600°C
Stem Diameter 6, 8, 10, 12, 14, 16mm
Stem Material AISI 304 SS / AISI 316 SS
Connection Size 1/2", 3/4", M22 x 1.5
Connection Type NPT, BSP, G, R, Metric etc
Capilarry Length Up to 50 Mtrs
Set Point Up to 2 Set Point
Terminal Box Position Bottom / Side
Option Glycerine filled
