RESISTANCE TEMPERATURE DETECTOR SANITARY TRI - CRIMP CONNECTOR - MODEL RTD06

RTD06 (Sanitary, Tri-Clamp)
Sensor Pt-100
No. Of Element Simplex/Duplex
Head Extension type Sanitary, Tri-Clamp
Wire Configuration 3 Wires
Range -200°C up to 400°C
Accuracy Class “B” As per IEC - 751 / DIN - 43760
Sheath Diameter 6 mm, 6.35mm, 3mm, 8mm
Sheath Material AISI 316 SS
Enclosure Protection IP 65/Flame Proof/Explosion proof
Enclosure Material Die-cast Aluminum/ AISI 304 SS
Process Connection 1½" Tri Clamp
Option ATEX, CSA & FM (Enclosure)

Download Send Enquiry

Applications

  • Food & Beverage Industries
  • Petrochemical Industries
