RESISTANCE TEMPERATURE DETECTOR CRIMP-ON POT SEALED - MODEL RTD03

RTD03 (Crimp - on Pot Sealed)
Sensor Pt-100
No. Of Element Simplex/Duplex
Head Extension type Crimp - on Pot Sealed
Wire Configuration 3 Wires
Range -200°C up to 400°C
Accuracy Class “B”
Sheath Diameter 6 mm, 4.5mm, 3mm, 8mm
Sheath Material AISI 316 SS
Element Length 300mm
Lead Wire Length Up to 3000mm
Process Connection Size 1/2”, 3/4”, 3/8”, M20
Process Connection Type NPT, BSP, G, R, Metric etc

Download Send Enquiry

Applications

  • Furnace, Ovens & Boilers
  • Machineries, Plats & Tanks
  • Water & Waste-water Treatment
  • Power & Utilities
